PV INPUT
*Recommedn PV Module Power(STC) Range: 430Wp--900Wp+
*Operation voltage range: 12V-60V, Maximum input voltage: 60V, Set-up voltage: 18V
*MPPT voltage range: 12V-48V
*Maximum continuous input current: 17A*2, Isc PV: 25A*2
AC INPUT AND OUTPUT(OFF-GRID PORT)
*Grid type: Single-phase
*Nominal AC voltage: 230V, Nominal AC frequency: 50Hz
*Maximum continuous output power: 1200VA, Max continuous input power: 1200VA
*Peak output apparent power: 1800VA, 10S
*Maximum continuous ouput current: 5.22A, Max continuous input current: 5.22A
LIFEPO4 BATTERY
*Nominal Energy: 2.6kWh, Nominal Capacity: 52Ah, Nominal Voltage: 51.2V
*Charging Voltage: 58.4V, Charge/Discharge protection voltage: 40V/58.4V
*Nominal charge/discharge current: 20A/20A, Max continuous charge/discharge current: 40A/40A
*Communication: CAN/GPS/Bluetooth, Built in WIFI & Bluetooth, Energy management:AP EasyPower APP
GENERAL SPECIFICATION
*Maximum Efficiency: 95.5%, Operating Ambient Temperature Range: -40℃---55℃
*Ingress Protection: IP66, Cooling: Natural convection-No fans, Max Altitude: ＜2000M
*Overvoltage Category: OVC II for PV and battery input circuit, OVC III for main circuit
*Frequency Range: 2412MHz-2472MHz(WiFi), 2402MHz-2480MHz(Bluetooth)
*RF output power(EIRP): 18.88 dBm(WiFi), 0.67dBm(Bluetooth)
COMPLIANCES
*Safety, EMC Compliances: EN62109-1/-2; EN62477-1; EN IEC 61000-6-1/-2/-3/-4; EN62920
*2 modules with STC ca.450W can be connected in parallel for each input channel, that means 2*2*450W
PRODUCT SIZE AND PACKING INFO
*Product size:440*390*235.2MM
